Asko TL751 - Page 14

13
4. INLETDUCT ASS'Y
A01
A02
A04
A05
A06
A03
4-1. Electric Type 4-2. Gas Type
A01 DUCT INLET REAR 3617510200 WE31'S, ALCOSTA 0.6T 1 ELECTRIC TYPE
3617510210 WG31'S, ALCOSTA 0.6T 1 GAS TYPE
A02 DUCT INLET FRONT 3617510300 WE31'S, ALCOSTA 0.6T 1 ELECTRIC TYPE
3617510310 WG31'S, ALCOSTA 0.6T 1 GAS TYPE
A03 HEATER AS 3612802500 240V 5000W 1 ELECTRIC TYPE
A04 THERMOSTAT HI-LIMIT 3619047600 125°C OFF / 94°C ON 250V 25A 1 ELECTRIC TYPE
A05 THERMOSTAT CUT-OUT 3619047800 140°C OFF / -35°C ON 250V 25A 1 ELECTRIC TYPE
A06
HARNESS HEATER(DRYER) 3612797000 UL.E-DRYER.MAIN-HARNESS 1 ELECTRIC TYPE
3612797300
UL/CSA, GAS-DRYER, ON/OFF-VALVE 1 GAS TYPE
- SCREW TAPPING 7122400811 T2S TRS 4x8 MFZN 12
FOR FIXING DUCT INLET F & R
- SCREW TAPPING 7122400811 T2S TRS 4x8 MFZN 4 FOR FIXING SENSOR
No. Part Name Part Code Description Qtt'y Remark
