GENOAD12M3-2Q
GENOAD12M3-2Q/H
GENOAD12M3/T
6 7
English
No. Description
1 Clear CMOS Pad (CLRMOS1)
2 Front VGA Header (VGA1)
3 PSU SMBus Header (PSU_SMB1)
4 ATX Power Connector (ATXPWR1)
5 Micro-Hi Power Connector (PWR1)
6 ATX 12V Power Connector (ATX12V1)
7 ATX 12V Power Connector (ATX12V2)
8 ATX 12V Power Connector (ATX12V3)
9 SATA SGPIO Connector (SATA_SGPIO3)
10 SATA SGPIO Connector (SATA_SGPIO4)
11 System Fan Connector (FAN1)
12 System Fan Connector (FAN2)
13 System Fan Connector (FAN3)
14 System Fan Connector (FAN4)
15 Mini Cool Edge IO Connector (MCIO1)
16 Mini Cool Edge IO Connector (MCIO2)
17 Mini Cool Edge IO Connector (MCIO3)
18 Mini Cool Edge IO Connector (MCIO4)
19 AMD Socket SP5 (SM-LGA-6096) (CPU1)
20 PWM Conguration Header (PWM_CFG1)
21 Mini Cool Edge IO Connector (MCIO5)
22 Mini Cool Edge IO Connector (MCIO6)
23 Mini Cool Edge IO Connector (MCIO7)
24 Mini Cool Edge IO Connector (MCIO8)
25 Auxiliary Panel Header (AUX_PANEL1)
26 System Panel Header (PANEL1)
27 USB 3.2 Gen1 Header (USB3_3_4)
28 System Fan Connector (FAN8)
29 System Fan Connector (FAN6)
30 System Fan Connector (FAN7)
31 System Fan Connector (FAN5)
32 COM Port Header (COM1)
33 SATA SGPIO Connector (SATA_SGPIO1)
