No. Description
34 SATA SGPIO Connector (SATA_SGPIO2)
35 3 x 288-pin DDR5 DIMM Slots (DDR5_B1, DDR5_D1, DDR5_F1)*
36 MC SMBus Header (BMC_SMB2)
37 MC SMBus Header (BMC_SMB1)
38 Intelligent Platform Management Bus Header (IPMB1)
39 M.2 Socket (M2_2) (Type 2260/2280/22110)
40 M.2 Socket (M2_1) (Type 2260/2280/22110)
41 NCSI Mode Jumper (NCSI_SEL1)
42 Chassis ID Jumper (CHASSIS_ID0)
43 Non Maskable Interrupt Button (NMI_BTN1)
44 Speaker Header (SPEAKER1)
45 Buzzer (BUZZER1)
46 3 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_C1, DDR5_E1)*
47 PCI Express 5.0 x16 Slot (PCIE6)
48 ermal Sensor Header (TR1)
49 PCI Express 5.0 x16 Slot (PCIE7)
50 OCP3 +12VSB Power Jumper (+12VSB_SEL1)
51 SPI TPM Header (TPM_BIOS_PH1)
52 OCP NIC 3.0 Slot (PCIe5.0 x16) (OCP3)
53 3 x 288-pin DDR5 DIMM Slots (DDR5_G1, DDR5_I1, DDR5_K1)*
54 3 x 288-pin DDR5 DIMM Slots (DDR5_H1, DDR5_J1, DDR5_L1)*
55 Backplane PCI Express Hot-Plug Connector (CPU1_HSBP1)
* For DIMM installation and conguration instructions, please see p.19 (Installation of Memory Modules
(DIMM)) for more details.
