GENOAD12M3-2Q
GENOAD12M3-2Q/H
GENOAD12M3/T
2 3
English
RJ45 1 dedicated IPMI
SFP+
GENOAD12M3-2Q, GENOAD12M3-2Q/H:
2 SFP28 (25GbE)
GENOAD12M3/T:
N/A
Internal Connectors/Headers
PSU Connector 1 (24-pin, ATX main power), 3 (8-pin, ATX 12V), 1 (8-pin
Micro-Hi power)
Auxiliary Panel
Header
GENOAD12M3-2Q, GENOAD12M3-2Q/H:
1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2
activity LED, locate, SMBus
GENOAD12M3/T:
1 (18-pin): chassis intrusion, system fault LED, locate, SMBus
System Panel Header 1 (9-pin): power switch, reset switch, system power LED,
HDD activity LED
NMI Button 1
COM Header 1 (9-pin)
VGA Header 1
Speaker Header 1 (4-pin)
Fan Header 8 (6-pin)
ermal Sensor
Header
1
TPM header 1 (13-pin, SPI)
SGPIO Header 4
HSBP 1
SMbus Header 2
PMbus Header 1
IPMB Header 1
Buzzer 1
Clear CMOS 1 (contact pads)
Others 1 ME manufacture mode header
LED Indicators
Standby Power LED 1 (5VSB)
80 Debug Port LED 1
Fan Fail LED 8
BMC Heartbeat LED 1
System BIOS
Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
Features ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance
wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
Hardware Monitor
Temperature CPU, MB, TR1 Temperature sensing
