Associated Research OMNIA II 8206 - Instrument Controls

21
RUN TEST MODE (MODELS 82X6 AND 82X7)
DUT POWER
Voltage
0 – 277 VAC Single Phase Unbalanced
(One Hot or Line conductor and One Neutral)
Current
16AAC max continuous
Voltage Display
Range:
0.0 – 277.0 VAC Full Scale
Resolution:
0.1 V
Accuracy:
 (1.5 of reading +0.2V), 30.0 – 277.0VAC
Short Circuit Protection
23 AAC, Response Time < 3s
DELAY AND DWELL TIMER SETTINGS
Delay time setting
Range: 0.2 – 999.9 seconds
Resolution: 0.1 second
Accuracy:  (0.1% + 0.05 sec)
Dwell time setting
Range: 0.1 – 999.9 seconds (0 = Continuous)
Resolution: 0.1 second
Accuracy:  (0.1% + 0.05 sec)
TRIP POINT SETTINGS
Voltage:
Volt-Hi
Volt-LO
Range: 30.0 – 277.0 VAC
Resolution: 0.1 V
Accuracy:  (1.5 of setting + 0.2 V), 30.0 – 277VAC
Current:
Amp-HI
Amp-LO
Range: 0.0 – 16.00 AAC
Resolution: 0.01 A
Accuracy:  (2.0 of setting + 2 Counts)
Watts:
Power-HI
Power-LO
Range: 0 – 4500 W
Resolution: 1 W
Accuracy:  (5.0 of setting + 3 Counts)
Power Factor:
PF-HI
PF-LO
Range: 0.000 – 1.000
Resolution: 0.001
Accuracy:  (8% of setting + 2 Counts)
Leakage Current:
Leak-HI
Leak-LO
Range: 0.00 – 10.00 mA (0 = OFF)
Resolution: 0.01 mA
Accuracy:  (2% of setting + 2 Counts)
Leakage current measuring resistor MD=2K  1%
METERING
Voltmeter
Range: 0.0 – 277.0 VAC
Resolution: 0.1 V
Accuracy:  (1.5 of reading + 2 Counts), 30.0 –
277VAC
Ammeter
Range: 0.0 – 16.00 AAC
Resolution: 0.01 A
Accuracy:  (2.0 of reading + 2 Counts)
Wattmeter
Range: 0 – 4500 W
Resolution: 1 W
Accuracy:  (5 of reading + 3 Counts)
METERING
