22
RUN TEST MODE (MODELS 82X6 AND 82X7)
Power Factor
Range: 0.000 – 1.000
Resolution: 0.001
Accuracy:  (8% of reading + 2 Counts)
Leakage Current
Range: 0.00 – 10.00 mA
Resolution: 0.01 mA
Accuracy:  (2 of reading + 2 Counts)
Leakage current measuring resistor MD = 2K  1%
Timer display
Range: 0.0 – 999.9 seconds
Resolution: 0.1 second
Accuracy:  (0.1 of reading + 0.05 seconds)
LEAKAGE CURRENT TEST MODE (82X6 AND 82X7 ONLY)
DUT POWER
Voltage
0 – 277 VAC
Current
16AAC max continuous
Voltage Display
Range:
0.0 – 277.0 VAC Full Scale
Resolution:
0.1 V
Accuracy:
 (1.5 of reading +0.2V), 30.0 –
277.0VAC
Short Circuit Protection
23 AAC, Response Time < 3s
DELAY AND DWELL TIMER SETTINGS
Delay time setting
Range: 0.5 – 999.9 seconds (AC+DC)
1.8-999.9 seconds (AC/DC Only and Auto Range)
1.3-999.9 seconds (AC/DC Only and Fixed Range)
Resolution: 0.1 second
Accuracy:  (0.1% + 0.05 sec)
Dwell time setting
Range: 0.0,0.5 – 999.9 seconds (AC+DC)
0.1-999.9 seconds (AC Only and DC Only)
(0 = Continuous)
Resolution: 0.1 second
Accuracy:  (0.1% + 0.05 sec)
LINE CONDITION
Reverse Power Switch
Reverse polarity switch setting select ON/OFF/AUTO
ON: Reverse power
OFF: Normal
AUTO: Automatic Reverse Polarity. With AUTO
mode, the polarity switches for normal conditions in
one step setting menu but will run two steps for both
conditions. In this mode, the unit only records and
displays the maximum leakage current value.
Neutral Switch
ON/OFF selection for single fault condition
Ground Switch
ON/OFF selection for Class I single fault condition
PROBE SETTING
