23
Surface to Surface (PH – PL)
Surface to Line (PH – L)
Ground to Line (G – L)
LEAKAGE LIMIT SETTING
Touch Current High Limit (RMS)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA / 1uA / 0.01mA
Touch Current Low Limit (RMS)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA/1uA/0.01mA
Touch Current High Limit (Peak)
Range:
0.0uA - 999.9uA
1000uA - 10.00mA
Resolution:
0.1uA/1uA/0.01mA
Touch Current Low Limit (Peak)
Range:
0.0uA - 999.9uA
1000uA - 10.00mA
Resolution:
0.1uA/1uA/0.01mA
DISPLAY
Touch Current Display (RMS)
Range 1
0.0uA ~ 32.0uA, frequency
DC, 15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2%
of reading + 3counts)
100KHz < f < 1MHZ : ±5% of
reading (10.0uA - 999.9uA)
Range 2
28.0uA ~ 130.0uA, frequency
DC, 15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2%
of reading + 3counts)
100KHz < f < 1MHZ : ±5% of
reading (10.0uA - 999.9uA)
Range 3
120.0uA ~ 550.0uA, frequency
DC, 15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2%
of reading + 3counts)
100KHz < f < 1MHZ : ±5% of
reading (10.0uA - 999.9uA)
