2-5
ASUS TS100-E10-PI4
Do not remove the PnP cap yet from
theCPUsocket.Doingsomaybend
thepinsofthesocket.
Retention tab
Load lever
2. Press the load lever with your thumb
(A),thenmoveittotheright(B)untilitis
released from the retention tab.
3. Lift the load lever until the load plate is
completely lifted.
Load plate
4. PositiontheCPUabovethesocket,
ensuringthatthegoldtrianglemarkis
onthebottom-leftcornerofthesocket,
thenttheCPUnotchestothesocket's
alignmentkeys.
TheCPUtsinonlyoneorientation.
DO NOT force the CPU into the
sockettopreventbendingthepinson
thesocketanddamagingtheCPU.
Gold
triangle
mark
CPU notches
Alignment
key
Alignment
key
