ASUS Z97M-PLUS

2-9

Chapter 2

2.1.7 Front I/O Connector

To install the system panel connector

USB 2.0

AAFP

To install USB 2.0 connector To install front panel audio connector

USB 3.0

To install USB 3.0 connector

HDD_LED
