Z97M-PLUS specifications summary
CPU
LGA1150 socket for the 4th, New 4th & 5th Generation Intel
®
Core™ i7/
Core™ i5 / Core™ i3, Pentium
®
, and Celeron
®
processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
Z97 Express Chipset
Memory
4 x DIMM, max. 32GB, DDR3 3200(O.C.)*/3100(O.C.)*/3000(O.C.)*/
2933(O.C.)*/2800(O.C.)*/2666(O.C.)*/2600(O.C.)*/2400(O.C.)*/
2250(O.C.)*/2200(O.C.)*/2133(O.C.)*/2000(O.C.)*/ 1866(O.C.)*/
1600/1333MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL (Qualified Vendors List) for details.
** Refer to www.asus.com for the Memory QVL (Qualified Vendors List).
Expansion slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 2.0 x16 slot (max. at x4 mode, compatible with PCIe x1
and x4 devices)
2 x PCI slots
Graphics Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D/RGB port
Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
Supports DVI-D with max. resolution of 1920 x 1200 @60Hz
Supports RGB with max. resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru™ 3D, Intel
®
Quick Sync Video, Intel
®
Clear Video
HD Technology, and Intel
®
Insider™
Supports up to three displays simultaneously
Maximum shared memory of 512MB
Multi-GPU support
Supports AMD
®
Quad-GPU CrossFireX™ Technology
Storage
Intel
®
Z97 Express Chipset with RAID 0, 1, 5, 10 and Intel
®
Rapid Storage Technology 13 support
- 1 x M.2 Socket 3*
- 6 x SATA 6.0 Gb/s ports (gray)
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology, and Intel
®
Smart Connect Technology**
* M.2 Socket 3 shares the bandwidth with SATA ports 5 and 6, and supports M
Key, type 2260/2280 storage devices.
** These functions will work depending on the CPU installed.
LAN
Gigabit Intel LAN controllers- 802.3az Energy Efcient Ethernet (EEE)
appliance
Intel
®
I218-V Gigabit LAN- Dual interconnect between the integrated
LAN controller and physical layer (PHY)
(continued on the next page)
