6 HIRO Installation Manual GDO-12V1
Technical Specifications GDO-12V1AM
Input voltage 120V
Frequency 60Hz
Current (max): 2A
Maximum pull force 400N
Type of door:
Max curtain weight:
Maximum door area (wind-lock):
Maximum door area:
Door must be well balanced and able to be operated by
hand, as per warranty conditions and standard UL 325
Rolling Sheet Door
352 lbs
236ft
2
*
301ft
2
Minimum sideroom 3
3
/
4
”
Receiver type Multi-frequency UHF
Receiver code storage capacity 64 x 4-button Transmitters
Number of code combinations Over 100 billion random codes
Transmitter battery CR2032 (3 Volts)
Courtesy light LED (Light Emitting Diodes)
Battery backup Battery compatible,
(requires optional Battery Backup kit)
Network connectivity Network compatible,
(requires optional Smart Phone Control Kit)
Type of entrapment protection Photo Electric Beam
*: Windy conditions can activate the obstruction feature of the opener.
3. System Specifications
