ATAGO RePo-1 - Page 14

-7-
90.0
Sample A Sample B Sample C
90.0% 100% 108%
g
g g g
Red light
Green light
Red light
Sample: Sucrose solution (26.0g/100mL)
+95.0% to +105%
Outside tolerance Within tolerance Outside tolerance
Red light Green light Red light
Outside tolerance
90.0%
Sample A
Within tolerance
100%
Sample B
Outside the tolerance
108%
Sample C
Red/Green Light Indication
〈Measurement Evaluation Indicator〉
Example: When the Purity scale is configured with a lower limit of 95.0% and an upper limit of 105%.
①Select the Purity scale.
②Press F to take a measurement.
--- will appear.
