Environmental
■
Mount on a wall or sturdy, level surface at least 2 feet (0.6 meters) from the floor. For ventilation,
Requirements
wall mounting is required for 2-module systems (strongly recommended for 1-module systems)
■
Locate within 5 feet (1.5 meters) of the network interface jacks and an electrical outlet not
controlled by a switch, using supplied 7-foot (2.1-meter) cords
■
Operating temperature 32° to + 104°F (0° to + 40°C), not in direct sunlight
■
Humidity 15%–90%, noncondensing
■
For proper ventilation and easy replacement of modules, provide at least 6 inches (2.34cm)
clearance at the top and sides and 2 feet (0.6 meters) at the front and bottom of the system
module(s).
■
Locate in an area free of excess moisture, corrosive gases, dust, and chemicals
Electrical
■
90–130 VAC, 50–60 Hz, 3-prong outlet separate ground, separately fused at 15 Amps
Requirements
On a PARTNER 220V System: 180–264 VAC, fused at 10 Amps
■
Outlet must not be controlled by an on/off switch
■
Grounding to comply with Underwriters Laboratories (UL) 1459:
A. An insulated grounding conductor that is not smaller in size and equivalent in insulation
material and thickness to the grounded and ungrounded branch circuit supply conductors,
except that it is green with or without one or more yellow stripes, is to be installed as part of the
circuit that supplies the product or system.
B.
The grounding conductor mentioned in item A is to be connected to ground at the service
equipment.
C.
The attachment-plug receptacles in the vicinity of the product or system are all to be of a
grounding type, and the grounding conductors serving these receptacles are to be connected
to earth ground at the service equipment.
Requirements for
Installation of a telephone or other standard (tip/ring) device in another building on continuous
Out-of-Building
property requires the following:
Extensions
■
MLS-model phone: two AT&T IROB protectors, plus carbon block protection or gas tube
protection
■
Standard device: one AT&T IROB protector or one AT&T OPRE, plus carbon block protection or
gas tube protection
Wiring
■
MLS-model phones: AT&T SYSTIMAX™ or at least 2-pair (4-wire) star (“home run” not “loop”)
■
Other standard telecommunications equipment (single-line phones, fax machines, answering
machines, etc.): 1-pair (2-wire) mounting cords (AT&T D2R mounting cords recommended)
■
Bridging adapter: AT&T 267F2
■
Range: 1,000 feet (305 meters) for MLS-model phones; 3,000 feet (915 meters) for standard
devices; or 17,000 feet (5,182 meters) for a standard touch-tone phone with an AT&T OPRE
Safety
U.S.: Meets UL 1459 Issue 2
Requirements
Canada Meets CSA C22.2, 225
Government
U.S.:
Approvals and
FCC Part 68
Local Phone
FCC registration number (U.S.): AS5 USA-61630-KF-E
FCC Part 15 Class B
Company
Information
REN (outside line jack): 0.9A per line jack
Canada:
DOC CP01, Issue 7
DOC registration number (Canada): 230 3756
DOC CS03, Issues 6 & 7
Load Number = 7
Jack type: RJ11C
Loop start lines
B-2
Specifications
