Specifications
B
Capacities System
206 Module Extension Jack
4 outside lines via line jacks on
2 outside lines
Maximum 2 devices per extension
two 206 modules or one 206 and
6 extensions
jack, total REN on jack not to
one 200 combination
exceed 2.0* (System phone
12 extensions via extension jacks
REN: 0.0 (zero))
on two 206 modules
200 Module
No more than one system phone
1 Music On Hold device via Music
2 outside lines
On Hold coupler to ext. jack 15
per jack
10 special application phones via
10 ext. jacks
Dimensions
206 module
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
4.5 lbs or 2.0 kgs
and Weights
200 module
11"(D) x 17"(H) x 1.5"(W) or 27.9 x 43.2 x 3.8 cm
(approx.)
4.0 lbs or 1.8 kgs
Two modules
12"(D) x 17"(H) x 5"(W) or 30.0 x 43.2 x 12.7 cm
10.5 lbs or 4.8 kgs
MLS-18D phone
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
2.8 lbs or 1.3 kgs
MLS-12D phone
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
2.8 lbs or 1.3 kgs
MLS-12 phone
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
2.7 lbs or 1.2 kgs
MLS-6 phone
9.5"(D) x 5"(H) x 6.75"(W) or 24.1 x 12.7 x 17.1 cm
2.7 lbs or 1.2 kgs
MLC-6 phone
9.4"(D) x 3.4"(H) x 7"(W) or 23.9 x 8.6 x 17.8 cm
2.8 lbs or 1.3 kgs
Switch Fabric
Full digital, nonblocking
Electrical
1 Amp per 206 module; .25 Amp per 200 module
Specifications
On a PARTNER 220V System: 0.6 Amp per 206 module; .25 Amp per 200 module
65 Watts per 206 module; 10 Watts per 200 module
Dissipation of power: 30W/206 module and 20W/200 module during normal operation
225 BTUs/hour per 206 module; 35 BTUs per 200 module
4-day memory backup (96 hours)
Extension
Ringing voltage: +5VDC, -140 VDC peak to peak; trapezoidal wave shaping
Jack
On a PARTNER 220V System: +5VDC, -150 VDC peak to peak
Specifications
35- to 38-Volt talk battery
Ringing frequency: 20 Hz
Proc. Module
80C321 microcontroller with 8K RAM and 64K ROM
Specifications
Music on
Electrical interfaces: one 657 jack to extension port one RCA phono jack to audio source
Hold Coupler
600 Ohm input on RCA jack ranging from 1mV to 4V
Specifications
*
The two devices combined on an extension jack can be a system phone with a standard device, or two standard devices; DO NOT
connect two system phones to the same extension jack. If a device lists two RENs, use the higher number when adding up RENs.
Specifications
B-1
