AT-610
User Manual
ATCOM TECHNOLOGY CO. , LIMITED
B 、 Push the other plate into the slot in accordance with the direction of the arrow .
C 、 Repeat
A
and B. It is the picture of wall mounting after fixing the two feet below:
D 、 Disassemble the feet way:
Press the plate with word “ PUSH ” and pull the feet with the direction of arrow. When the
plate is pull out of the slot (there will be a sound of “ pa ” ) you can take off the feet .
Attention: Please rotate the hook to the position as in
picture with a coin or other tools
