ATEQ F6 Profinet Series - Page 36

35 / 75
FG_F6_PROFINET_EN_04 / 2020-06-17
Example: bit number 13 (automatic mode) activated to 1, will place to "2000h" the value in the first
word.
2000h is equivalent to 8192 in decimal and 0010000000000000 in binary.
In the Modbus frame, the words will follow each other: word 1 + word 2 + ….. + word n.
Word
Bit n°
Mask
Meaning
Menu
Hexa
Dec
7
96
0001
1
Buzzer function.
+Funct
97
0002
2
Long test (x100) function.
+Funct
98
0004
4
Permanent blowing.
Conf
99
0008
8
Sealed Diff component function.
+Funct
100
0010
16
Test or Ref Mode.
+Funct
101
0020
32
Display optional.
+Funct
102
0040
64
Pressure Drop.
+Funct
103
0080
128
Pressure correction (≥v1.400).
+Funct
104
0100
256
Standard conditions (≥v1.400).
+Funct
105
0200
512
Ref No Dump.
+Funct
106
0400
1024
Auto Vol.
+Funct
107
0800
2048
Offset.
+Funct
108
1000
4096
Old Flow Calcultion.
+Funct
109
2000
8192
Reserved.
110
4000
16384
Auto Selection Prog.
Conf
111
8000
32768
Save Volume Selection.
Conf
