Special cycles
Special cycle table
Write the identifier number of the wanted special cycle at the address 04(h) and its instruction if
necessary.
@08(h) = identifier number of the special cycle
@09(h) = instruction for the special cycle
Numb
Special cycle
Numb
Special cycle
1
ATR Learning Cycle
17
Sd Prt FAIL Learn
2
Test Check Result
18
Direct P. Check (*) (**)
3
AUTO TEST
19
Leak Sensor Check (*) (**)
4
Custom Unit Learn
20
Reserved
5
Custom Unit Check
21
Reserved
6
ATR+Custom Learn
22
Reserved
7
Piezo auto zero Reg 1
23
No special cycle
8
Piezo auto zero Reg 2
24
Reserved
9
Regul. 2 adjust
25
Line P. Sensor Check (*) (**)
10
Regulator Adj
26
No special cycle
11
Infinite fill
27
Reserved
12
Volume Comp
28
Reserved
13
Auto Vol
29
Temperature check (*) (**)
14
No special cycle
30
Atm Pressure Check (*) (**)
15
No special cycle
31
No special cycle
16
Sd Prt PASS Learn
To activate a special cycle, you must send a Start command (Bit 1) and a Start special cycle command
(Bit 2).
(*) For version ≥ 1.400 only.
(**) Appears with the Service special cycle function checked.
