Identifier N°
Meaning
Value
Dec
Hexa
485
01 E5
“EXT. ACCES”
Security by external access (Fieldbus/Modbus)
Reset value with Modbus:
→ Writing at address 0xC1E5
Reset value with Fieldbus:
→ Writing one word with ID = 0xC1E5
Read/Write
Read Only
No Access
0000
1000
2000
486
01 E6
“OFFSET”
Offset Learning
- 9999 > 9999
Regulator selection
Regulator selection for fill and pre-fill (word 1, bit n°0 and 1) in the table of the functions bits.
Fill regulator
Pre-fill regulator
Regulator 1
0
0
Regulator 2
1
1
Configurable input values
F6 V1.3XX
Input value
Value code
Input value
Value code
Program Selection
0000
Atr Learning Cycle
17000
P1 Sensor Check (*)
4000
Sd Prt Pass Learn
18000
P1 Reg1 Check (*)
5000
Sd Prt Fail Learn
19000
P2 Sensor Check (*)
6000
Volume Comp.
20000
Leak Sensor Check (*)
7000
Test Check Result
21000
Auto Test (*)
8000
Step By Step
22000
Regul. 2 Adjust
9000
Auto Setup
23000
Regul. 1 Adjust
10000
Atr+Custom Learn.
24000
Part Regulator
11000
Code Reader
25000
Infinite Fill
12000
Auto Vol
26000
Piezo Auto Zero
13000
Test On Caps
27000
Custom Unit Learn
14000
Temp.2 Corr. Learn
30000
Custom Unit Check
15000
Temp.2 Sensor Read
31000
Chck+Lrn Cust. Unit
16000
(*) Available when the Service special cycle function is checked.
