Function
Table of the function bits
Table of the function bits per program.
Reminder: “h” indicates a hexadecimal code, “(d)” indicates a decimal code.
The bits below are present in the FUNCTIONS menu of each program, if these have been previously
validated in the More functions... menu.
Word
Bit n°
Mask
Meaning
Menu
Hexa
Dec
1
0
0001
1
Fill regulator Number.
Funct
1
0002
2
Pre-fill regulator Number.
Funct
2
0004
4
Fill type function.
Funct
3
0008
8
Pre-fill type function.
Funct
4
0010
16
Recovery level function.
Funct
5
0020
32
End of cycle function.
Funct
6
0040
64
Automatic reset end cycle function.
Funct
7
0080
128
Reset and dump end of cycle function.
Funct
8
0100
256
Fill mode end of cycle function.
Funct
9
0200
512
Peak hold function.
Funct
10
0400
1024
Reference volume function.
Funct
11
0800
2048
ATR0 function.
Funct
12
1000
4096
ATR1 function.
Funct
13
2000
8192
ATR2 function.
Funct
14
4000
16384
Sequencing function.
Funct
15
8000
32768
Pass part sequencing function.
Funct
2
16
0001
1
Fail test part sequencing function.
Funct
17
0002
2
Fail reference part sequencing
function.
Funct
18
0004
4
Alarm sequencing function.
Funct
19
0008
8
Pressure fault sequencing function.
Funct
20
0010
16
End of cycle sequencing function.
Funct
21
0020
32
Mini valve function.
Funct
22
0040
64
Recovery part sequencing function.
Funct
23
0080
128
Calibration check sequencing function.
Funct
24
0100
256
Automatic connector function.
Funct
25
0200
512
Calibration check function.
Funct
26
0400
1024
Valve code function.
Funct
27
0800
2048
External valve code 1 function.
Funct
28
1000
4096
External valve code 2 function.
Funct
29
2000
8192
External valve code 3 function.
Funct
30
4000
16384
External valve code 4 function.
Funct
31
8000
32768
External valve code 5 function.
Funct
