ATEQ F6 Profinet Series - Page 41

FG_F6_PROFINET_EN_04 / 2020-06-17
40 / 75
Word
Bit n°
Mask
Meaning
Menu
Hexa
Dec
3
32
0001
1
External valve code 6 function.
Funct
33
0002
2
Internal valve code 1 function.
Funct
34
0004
4
Internal valve code 2 function.
Funct
35
0008
8
Stamp function.
Funct
36
0010
16
Pass part stamp function.
Funct
37
0020
32
Fail test part stamp function.
Funct
38
0040
64
Fail reference part stamp function.
Funct
39
0080
128
Alarm stamp function.
Funct
40
0100
256
Pressure fault stamp function.
Funct
41
0200
512
End of cycle stamp function.
Funct
42
0400
1024
Recovery part stamp function.
Funct
43
0800
2048
Calibration check stamp function.
Funct
44
1000
4096
N test function.
Funct
45
2000
8192
Reserved.
46
4000
16384
Sealed components function (Leak unit
always PA, not changeable).
Funct
47
8000
32768
Reserved.
4
48
0001
1
External dump function.
Funct
49
0002
2
Temperature correction function.
Funct
50
0004
4
Recovery test or indirect mode
function.
Funct
51
0008
8
Dump before sealed component.
Funct
52
0010
16
Sign change function.
Funct
53
0020
32
Obligatory reset on end of cycle.
Funct
54
0040
64
Auxiliaries codes function.
Funct
55
0080
128
Auxiliaries codes 1 function.
Funct
56
0100
256
Auxiliaries codes 2 function.
Funct
57
0200
512
Auxiliaries codes 3 function.
Funct
58
0400
1024
Auxiliaries codes 4 function.
Funct
59
0800
2048
Auto param function (not available).
Funct
60
1000
4096
Filtering function.
Funct
61
2000
8192
Bar code function.
Funct
62
4000
16384
Flow reject function.
Funct
63
8000
32768
No negative function.
Funct
