ATEQ F6 Profinet Series - Page 43

FG_F6_PROFINET_EN_04 / 2020-06-17
42 / 75
Word
Bit n°
Mask
Meaning
Menu
Hexa
Dec
9
128
0001
1
Old Flow Calcultion.
Funct
129>143
Reserved.
Example: bit number 46 (Offset function) activated on 1, will put to "4000h" the value in the third
word.
4000h is equivalent to 16384 in decimal and 0100000000000000 in binary.
In the Modbus frame, the words will follow as such: word 1 + word 2 + ….. + word n.
