ATI Technologies Q46-85 - Spare Parts

65
O&M Manual
Rev F (8/17)
Spare Parts
Electronics
03-0385-6 Q46/85 Front lid assembly
07-0310 Q46/85 Monitor, 100-240 VAC
07-0311 Q46/85 Monitor, 12-24 VDC
07-0314 Q46/85 Monitor, 100-240 VAC, w/Profibus
07-0315 Q46/85 Monitor, 12-24 VDC, w/Profibus
23-0029 Fuse, T-Lag, 630mA, 250V, TR-5 (for AC and DC Analyzers)
38-0072 Terminal block plug, 3 position (relays)
38-0073 Terminal block plug, 4 position (outputs)
38-0074 Terminal block plug, 3 position (shields)
38-0081 Terminal block plug, 3 position (power)
38-0084 Terminal block plug, 3 position (power) – VDC version*
*NOTE: prior to Dec 2018, VDC (power) Terminal block used the (38-0081)
03-0407 Q46 P/S Assy, 100-240 VAC
03-0408 Q46 P/S Assy, 100-240 VAC with 3
rd
4-20mA output
03-0409 Q46 P/S Assy, 100-240 VAC with 3 relay exp. Board
03-0410 Q46 P/S Assy, 12-24 VDC
03-0411 Q46 P/S Assy, 12-24 VDC with 3
rd
4-20mA output
03-0412 Q46 P/S Assy, 12-24 VDC with 3 relay exp. Board
Sensors
00-1620 PAA sensor, flow type
07-0096 Q22 pH Sensor, no cable
63-0101 Conventional pH Sensor with solution ground, 25 ft. cable
Sensor Components
02-0018 Sensing element body, (for #00-1620)
03-0029 Sensor interconnect cable with connector, 25 ft.
45-0007 Electrolyte chamber
45-0290 Membrane holder, type Kynar
05-0090* Membranes, pkg. of 10
05-0004* Spare Parts Kit, screw & o-ring
09-0060* Peracetic acid electrolyte, 4 oz (120 cc)
Flowcells
00-0043 Constant-Head Flowcell assembly with mounting plate
00-1522 Sealed flowcell assembly with mounting plate
00-1527 Sealed pH flowcell assembly with mounting plate
42-0014 Flowcell o-ring (each)
Misc. Components
07-0100 Universal Junction Box, NEMA 4X
07-0382 Junction Box for 2
nd
Input Sensor
31-0038 Interconnect cable for junction box to monitor wiring .
03-0371 Fixed Flow Regulator assy (w/25’ tubing)
44-0276 Black Polyurethane tubing
05-0101 Vacuum Breaker Assy
Note: Instrument is supplied with sufficient spare parts for 6-12 months of operation. For 2 year spare parts
inventory, 3 each of the items marked with an asterisk are required.
