ATI Technologies Q46-85 - Figure 23 - Software Map

ATI Q46H/85 PAA System Part 6 – Configuration
34
O&M Manual
Rev F (8/17)
Start
(display only)
MEASURE
CAL CONFIG DIAG
ENTER
MENU
ESC
or
or
or
Cal
*PID 0% #1
Set Hold
** Cal pH
*PID 100% #1
*PID Setpoint #1
*PID Prop #1
Setpnt B
Fault List
Sim Out
Fail Out #1
Fail Val #1
Fail Out #2
** pH
Temperature
* PID % Output
Loop Current (#1)
LIST
ITEMS
Cal Temp
Loop Current (#2)
Delay B
Hyst B
Relay B= FAIL
Relay B= CON
Set Default
Setpnt A
Delay A
Phase A
Hyst A
Relay A= AL
Relay A= FAIL
Relay A= CON
Setpnt A- HI
Delay A- HI
Setpnt A- LO
Hyst A- HI
Delay A- LO
Hyst A- LO
Phase B
Slope
CONTROL
Fail Val #2
Failsafe
* If PID is enabled
** If pH is enabled
*** If pH is enabled and
Instrument is a Type
Q45H0
*PID Int #1
*PID Deriv #1
Set 4mA (#1)
Set 20mA (#1)
or
Entry Lock
Set Delay
Contrast
Main Display
I out 1 Mode
I out 2 Mode
Relay A Mode
Relay B Mode
Temp Units
pH Input
Set 4mA (#2)
Set 20mA (#2)
nA
Offset
*PID Timer
*** pH Comp.
Set Range
MENU
SECTIONS
** mV
Main Units
Zero Filter
** pH Buffer
Phase A
Software Version
** pH Slope
** pH Offset
* pH Type
MENU
ESC
ENTER
MENU
ESC
MENU
ESC
MENU
ESC
ENTER ENTER
Figure 23 - Software Map
