Atlantic 200L - Dimensions;Structure

48
G
Overview Installation Use Maintenance Warranty
6. Dimensions/structure
B
A
D
C
E
F
60°
Dimensions in mm
Ref
MODEL
200 200
COIL
270 270
COIL
A Condensate outlet
1166
1166
1525
1525
B Total height
1617
1617
1957
1957
C Cold water inlet 304 462 304 462
D Hot water outlet 961 961
1300
1300
E Total width 620 620 620 620
F Total depth 665 665 665 665
G Inlet dimensions 418 418 418 418
H Exchanger inlet - 640 - 640
H
INOUT
È
È
