In the event of a fault, or when no heat or steam is issued from the filling point, switch off the power supply
and inform your installer.
4. Fault diagnostic.
Code displayed
Causes Consequences Troubleshooting
Error 03
Water temperature
sensor defective or
out of range
Not possible to read
the water
temperature: no
heating.
Check
the connection (A1 mark) of the
water
temperature
sensor (thermowell). Check
the
sensor
resistance (see table below).
If
necessary, replace the sensor.
Error 07
No water in the tank
or open ACI link
No heating
Fill
the tank with water.
Check
the wiring connection (AC mark),
the
conductivity
of the water.
Error 09
Water temperature
too high (T>80°C)
Risk of triggering
mechanical safety:
no heating
Check
if the actual water temperature at
the
water
outlet is high (T>80°C).
Check
the connection (A1 mark) and
the
position
of the water temperature
sensor
(thermowell),
it must be on the stopper.
Check
that the electrical backup is not
running
continuously
. Reset the mechanical safety
if
necessary
.
Water too cold
Water temperature
too cold (T<5°C)
HP stopped.
Heating in ELEC.
Automatic
reset when T>10° C. Check
the
conformity
of the installation (frost-free room).
Error 21
Air inlet sensor
defective or out of
range (-20 to 60°C)
HP stopped.
Heating in ELEC.
Check
the connections (A4 mark) and
the
positioning
of the incoming air sensor.
Check
the
sensor resistance (see table below).
If
necessary,
replace the sensor wiring bundle.
Error 22.1
Top e va po rator
sensor defective or
out of range (
-
20 to
110)
HP stopped.
Heating in ELEC.
Check
the connections (A4 mark) and
the
correct
positioning of the sensor on its tube.
Check
the fan's operation ensuring that it
turns
freely
and without stopping (mark M1) and
the
power
supply on the terminal block
Check
the sensor resistance (see table below).
Error 22.2
Bottom evaporator
sensor defective or
out of range (
-
20 to
110)
HP stopped.
Heating in ELEC.
Check
the connections (A4 mark) and
the
correct
positioning of the sensor on its tube.
Check
the fan's operation ensuring that it
turns
freely
and without stopping (mark M1) and
the
power
supply on the terminal block
Check
the sensor resistance (see table below).
Troubleshooting operations must be carried out exclusively by a professional.
4.1. Display of error codes.
The alarm can be turned off or reset by pressing OK.
