gure 39 - Description of the hydraulic unit electric control box
HP controller
Cable grommets (power)
Interface Board
Cable grommets
(sensors)
Terminal
Installation manual "1872 - EN" - 43 -
Alféa Extensa A.I. Heat Pump
