Atlantic Alfea Extensa A.I. - Description of the equipment; Packing; Unpacking and supplies; Definitions

1.1 Packing
• 1 package: Outdoor unit.
• 1 package: Hydraulic unit and outdoor temperature
sensor.
1.2 Unpacking and supplies
While the courier is still present, carefully check the
general appearance of the appliances and check
that the outdoor unit has not been laid in a horizontal
position.
In the event of a dispute, send any relevant reservations
to the carrier in writing within 48 hours and send a copy
of the letter to Customer Services.
1.3 Denitions
- Split: The heat pump consists of two elements
(an outdoor unit to be installed outdoors and a hydraulic
unit to be installed inside the dwelling).
- Air/water: The surrounding air is the energy source.
This energy is transmitted to the heating circuit water
by the heat pump.
- Inverter: The fan and compressor speeds are
modulated according to the heating requirements.
This technology enables you to save on energy and
operate on a single-phase power supply, whatever
the heat pump's output, by avoiding pulling signicant
amounts of current at start-up.
- COP (Coe󰀩cient of Performance): This is the
relationship between the energy transmitted to the
heating circuit and consumed electrical energy.
1 Description of the equipment
Installation manual "1872 - EN"
Alféa Extensa A.I. Heat Pump
- 6 -
Packing contents list
Heat Pump Outdoor unit Hydraulic unit
Model
Export
code
Reference Code Reference Code
Alféa Extensa A.I. 5 526230
WOYA060LFCA 700171
Alféa Extensa A.I. 5 024124
Alféa Extensa A.I. 6 526231
Alféa Extensa A.I. 6-8-10 024125
Alféa Extensa A.I. 8 526232 WOYA080LFCA 700172
Alféa Extensa A.I. 10 526233 WOYA100LFTA 700173
Alféa Extensa A.I. 13 526234 WOYG112LHT 700179
Alféa Extensa A.I. 13-16 024126
Alféa Extensa A.I. 16 526235 WOYG140LCTA 700175
Optional equipment
• Dual circuit kit (code 074025)
for connecting 2 heating circuits.
• Electrical back-ups kit (code 074044)
• DHW kit (code 073991)
for connecting a mixed DHW tank
(with built-in electrical backups).
• Boiler connection kit (code 073989)
for connecting a boiler to the heat pump.
• Wireless room sensor A59 (code 074208) for
correcting the ambient temperature.
• Wireless room sensor A75 (code 074213),
Wireless room sensor A78 (code 074214)
for correcting the ambient temperature and
programming the heat pump.
• Cooling kit (code 075328).
• High ow rate circulation pump kit (code 074077)
for the installation of 1 underoor heating circuit.
• Anti-vibration blocks (code 523574).
• White PVC oor support (ref. 809532) or
Black rubber oor support (ref. 809536).
Operating Range
This heat pump provides:
- Heating in winter,
- The management of electrical backups*, for extra
heating on the coldest days,
or
- Installation with boiler connection* for extra heating on
the coldest days,
- Management of two heating circuits*,
- Production of domestic hot water* (provided that it is
combined with a mixed DHW tank),
- Cooling in summer* (for underoor heating-cooling
system or fan-convectors).
*: These options require the use of additional kits (see chapter
"Required accessory" or "Optional equipment").
