9 Basic Hydraulic Layout
• Conguration 1: 1 heating circuit
SE
PC
MH
R
Rdyn*
CC
OU
OU
SA
SA*
SA
BT*
SP
Key: EB - Electrical backup BT* - Bu󰀨er tank (obligatory with Rdyn) CC - Heating circulation pump MH - Hydraulic unit PC - Underoor heating system
R - Radiator Rdyn* - Dynamic radiator SA* - Room sensor (option/ except with Rdyn) SE - Outside sensor SP - Heated oor thermal safety fuse
Installation manual "1872 - EN"
Alféa Extensa A.I. Heat Pump
- 72 -
