Atlantic Alfea Extensa A.I. User Manual

• Conguration 1: 1 heating circuit and mixed hot water tank
SE
PC
MH
R
Rdyn*
CC
OU
OU
SA
SA*
SA
BT*
SP
AE
Ssa
M
B
A
AB
VD
KS
Key: EB - Electrical backup BT* - Bu󰀨er tank (obligatory with Rdyn, if HP>11kW) CC - Heating circulation pump KS - DHW kit
MH - Hydraulic unit PC - Underoor heating system R - Radiator Rdyn* - Dynamic radiator SA* - Room sensor (option/ except with Rdyn) SSa - Hot water sensor
SE - Outside sensor SP - Heated oor thermal safety fuse VD - Distribution valve
