Alféa Extensa A.I. Heat Pump
Trade name / Product name: Atlantic / Alféa ... Extensa A.I. 5 Extensa A.I. 6 Extensa A.I. 8 Extensa A.I. 10
Export code 526230 526231 526232 526233
Heating applications 35°C 55°C 35°C 55°C 35°C 55°C 35°C 55°C
Declared performance coe󰀩cients with a partial load for an indoor temperature of 20°C and an outdoor temperature of Tj
Tj = -7°C COP
d
- 2.86 1.86 2.65 1.79 2.35 1.77 2.35 1.74
Tj = +2°C COP
d
- 4.10 2.82 4.17 2.86 3.82 2.93 3.81 2.74
Tj = +7°C COP
d
- 5.00 4.00 5.99 4.03 5.69 4.12 5.71 4.10
Tj = +12°C COP
d
- 8.12 5.84 8.29 5.84 8.16 5.81 7.16 5.72
Tj = bivalent temperature COP
d
- 2.86 1.86 2.65 1.79 2.35 1.77 2.35 1.74
Tj = operating temperature limit COP
d
- 2.65 1.54 2.57 1.56 2.02 1.47 2.16 1.44
For air/water heat pumps: operating temperature
limit
TOL °C -10 -10 -10 -10 -10 -10 -10 -10
Maximum heating water operating temperature WTOL °C 55 55 55 55 55 55 55 55
Backup heater
Rated heat output
(2)
P
sup
kW 0.6 1.1 0.7 1.0 0.9 1.2 1.4 1.7
Type of energy used - - Electric
Electricity consumption in modes other than the active mode
Shutdown mode P
OFF
W 6 6 6 6 6 6 5 5
Thermostat shutdown mode P
TO
W 19 17 23 16 30 16 43 22
Standby mode P
SB
W 10 10 10 10 9 9 8 8
Casing resistance mode P
CK
W 0 0 0 0 0 0 0 0
Other characteristics
Power control
- - Inverter
For air/water heat pumps, rated air ow rate,
outdoors
- m
3
/h 2070 2340 3600 6200
(1) The calculation details are available on the package datasheet. The room unit refers to: sensors, thermostats and remote controllers included, or not included, in the kits.
(2) For heat pump space heaters and heat pump combination heaters, the rated heat output P
rated
is equal to the rated caloric load P
designh
, and the rated heat output of the
backup heater P
sup
is equal to the caloric output of the extra backup heating (Tj).
(3) If Cdh is not determined by measurement then the default degradation coefcient is Cdh=0.9.
