User Interfaces BLM 3750 User Guide
16 (78) 9836 3078 01 Edition 2.0
3 User Interfaces
3.1 Static transducers
The standard BLM 3750 bench features a set of static transducer SRTT-B:
Static transducers are designed to test:
• Impulse power tools. When the impulse tool has a shut-off valve, a mechanical joint simulator is
required.
• Wrenches
• Power tool, for those special cases in which the test on the hydraulic would be not possible. In
this case, to permit the tool to rotate, a mechanical joint simulator must be mounted on the static
transducer.
To install a mechanical joint simulator, insert the simulator in the SRTT-B, and tighten the lever before
starting the test:
To Next Page
