Units GA90 GA110 GA132 GA160 GA200 GA250
Minimum cooling water flow l/s 0.7 0.8 0.9 1.1 1.3 1.6
Minimum cooling water flow cfm 1.5 1.7 1.9 2.3 2.8 3.4
Data for GA 13 bar (189 psi) 50 Hz compressors
Units GA90 GA110 GA132 GA160 GA200 GA250
Maximum working pressure, GA Pack bar(e) 13 13 13 13 13 13
Maximum working pressure, GA Pack psig 189 189 189 189 189 189
Maximum working pressure, GA Full-
Feature
bar(e) 12.75 12.75 12.75 12.75 12.75 12.75
Maximum working pressure, GA Full-
Feature
psig 185 185 185 185 185 185
Nominal working pressure bar(e) 12.5 12.5 12.5 12.5 12.5 12.5
Nominal working pressure psig 181 181 181 181 181 181
Motor shaft speed r/min 1490 1490 1490 1490 1490 1490
Power input, GA Pack kW 104 124 149 182 241 289
Power input, GA Pack hp 139 166 200 244 323 388
Power input, GA Full-Feature kW 110 130 158 191 258 306
Power input, GA Full-Feature hp 148 174 212 256 346 410
Power input, GA W Pack kW 101 121 144 177 233 281
Power input, GA W Pack hp 135 162 193 237 312 377
Power input, GA W Full-Feature kW 106 126 152 185 250 298
Power input, GA W Full-Feature hp 142 169 204 248 335 400
Oil capacity, GA l 69 75 93 100 130 130
Oil capacity, GA US gal 18.2 19.8 24.6 26.4 34.3 34.3
Oil capacity, GA Imp gal 15.2 16.5 20.5 22 28.6 28.6
Oil capacity, GA cu.ft 2.42 2.63 3.26 3.5 4.55 4.55
Oil capacity, GA W l 63 63 85 85 113 113
Oil capacity, GA W US gal 16.6 16.6 22.4 22.4 29.8 29.8
Oil capacity, GA W Imp gal 13.9 13.9 18.7 18.7 24.9 24.9
Oil capacity, GA W cu.ft 2.21 2.21 2.98 2.98 3.96 3.96
Sound pressure level, GA dB(A) 72 72 74 74 75 75
Sound pressure level, GA W dB(A) 71 71 71 71 72 72
Maximum cooling water flow l/s 2.0 2.5 3.0 3.6 4.2 5.6
Maximum cooling water flow cfm 4.2 5.3 6.4 7.6 8.9 11.9
Minimum cooling water flow l/s 0.7 0.8 0.9 1.1 1.3 1.6
Minimum cooling water flow cfm 1.5 1.7 1.9 2.3 2.8 3.4
Data for GA 6.9 bar (100 psi) 60 Hz compressors
Units GA90 GA110 GA160 GA200 GA250 GA315
Maximum working pressure, GA Pack bar(e) 7.4 7.4 7.4 7.4 7.4 7.4
