Units GA90 GA110 GA160 GA200 GA250 GA315
Maximum working pressure, GA Pack psig 107 107 107 107 107 107
Maximum working pressure, GA Full-
Feature
bar(e) 7.15 7.15 7.15 7.15 7.15 7.15
Maximum working pressure, GA Full-
Feature
psig 104 104 104 104 104 104
Nominal working pressure bar(e) 6.9 6.9 6.9 6.9 6.9 6.9
Nominal working pressure psig 100 100 100 100 100 100
Motor shaft speed r/min 1790 1790 1790 1790 1790 1790
Power input, GA Pack kW 109 133 178 217 254 291
Power input, GA Pack hp 146 178 239 291 341 390
Power input, GA Full-Feature kW 116 140 188 234 271 309
Power input, GA Full-Feature hp 156 188 252 314 363 414
Power input, GA W Pack kW 105 128 171 208 245 282
Power input, GA W Pack hp 141 172 229 279 329 378
Power input, GA W Full-Feature kW 112 134 181 225 262 300
Power input, GA W Full-Feature hp 150 180 243 302 351 402
Oil capacity, GA l 69 75 100 130 130 130
Oil capacity, GA US gal 18.2 19.8 26.4 34.3 34.3 34.3
Oil capacity, GA Imp gal 15.2 16.5 22 28.6 28.6 28.6
Oil capacity, GA cu.ft 2.42 2.63 3.5 4.55 4.55 4.55
Oil capacity, GA W l 63 63 85 113 113 113
Oil capacity, GA W US gal 16.6 16.6 22.4 29.8 29.8 29.8
Oil capacity, GA W Imp gal 13.9 13.9 18.7 24.9 24.9 24.9
Oil capacity, GA W cu.ft 2.21 2.21 2.98 3.96 3.96 3.96
Sound pressure level, GA dB(A) 76 76 78 76 76 76
Sound pressure level, GA W dB(A) 71 71 71 72 72 72
Maximum cooling water flow l/s 2.0 2.5 3.6 4.2 5.6 6.9
Maximum cooling water flow cfm 4.2 5.3 7.6 8.9 11.9 14.6
Minimum cooling water flow l/s 0.7 0.8 1.1 1.3 1.6 1.8
Minimum cooling water flow cfm 1.5 1.7 2.3 2.8 3.4 3.8
Data for GA 8.6 bar (125 psi) 60 Hz compressors
Units GA90 GA110 GA160 GA200 GA250 GA315
Maximum working pressure, GA Pack bar(e) 9.1 9.1 9.1 9.1 9.1 9.1
Maximum working pressure, GA Pack psig 132 132 132 132 132 132
Maximum working pressure, GA Full-
Feature
bar(e) 8.85 8.85 8.85 8.85 8.85 8.85
Maximum working pressure, GA Full-
Feature
psig 128 128 128 128 128 128
Nominal working pressure bar(e) 8.6 8.6 8.6 8.6 8.6 8.6
Nominal working pressure psig 125 125 125 125 125 125
Instruction book
2920 1475 06 125
