Transport fixtures for GA 200, GA 250 and GA 315 60 Hz
Step Action
1 The gear casing supports, motor support and air receiver supports are secured to the
frame, immobilising the vibration dampers during transport.
2 Remove the bushes (1) from the gear casing supports and the motor support.
3 Remove the brackets fitted next to the air receiver supports.
Instruction book
78 2920 1475 06
