Atlas Copco Power Focus 4000 Graph User Manual

37
E540 Calibration not OK,
CalVal changed > 5%
of max value since last
calibration
- Calibration not OK, calibration value
changed > 5% of max value since last
calibration.
E541 Other calibration error Yes
E550 Radio contact with
tool established, tool
accessible
Radio contact with tool established,
tool accessible.
E551 Radio contact with tool
lost, tool inaccessible
Radio contact with tool, lost inac-
cessible
E552 DASP Communication
error with tool
Communication error between tool
and controller on DASP level. Not
possible to read or write from/to an
ALP reference.
E553 Pairing attempt with
wireless tool failed
An attempt to pair the Power Focus
with a wireless tool failed.
E554 Command not per-
formed, wireless tool
inaccessible
A command (batch increment, reset
batch etc.) could not be performed and
was discarded because the tool was
currently inaccessible.
E555 Condition change not
refl ected in tool, wire-
less tool inaccessible
A condition change in the controller
(Pset selection, Job selection, Job
aborted etc.) could not be refl ected
in the tool. The tool was currently
inaccessible.
E556 Tool battery low Tool bat-
tery low.
E600-E699: Hardware errors DC3000/MC3000
E601 Dcbus LO at start of
rundown
Yes DC voltage too low
E603 Drive overheated The DC drive is too hot, drive
deactivated.
E618 Drive HW/SW mis-
match
Drive hardware and software
mismatch. Check motor type in Tools
Talk DS/DL.
E619 Drive deactivated DC drive deactivated during operation.
E620 Tool stall Tool motor stall.
E621 High current offset High current offset at tightening start.
E625 Dcbus Lo, primary Restart controller. If problem still remains
check line voltage.
