E500-E599: Hardware errors TOOL
E501 Tool overheated - The tool is too hot. The drive is disabled.
E502 Tool service interval
expired
-
E503 Calibration date expired
The calibration date has expired.
E504 Tool wear indicator alarm Tool wear indicator alarm indicates that
the tool should be serviced.
E505
Tool rebuilt to/from
OE-type
Tool redesigned. E.g. angled tool type
redesigned to an OE-tool-type
E510 Tool type not supported
by RBU
The tool type is not supported by RBU.
E511 Tool-PF3000 size
mismatch
Yes Mismatch between the tool and the
controller (for example S4/S7 tool con-
nected to a S9 controller).
E513 Tool EEPROM corrupt
– service tool
Ye s
E514 Tool EEPROM corrupt
– Motortune
Ye s
E517 Tool maxtorque or Gear
Ratio out of range
Ye s
E518 Tool normalisation out
of range
-
E519 Tool calibration value
out of range
Tool calibration value out of range,
service tool.
E520 Wear indicator data in
tool invalid
Data in tool memory used for wear
indicator is invalid. Service tool.
E531 Communication error Communication error. Restart the controller.
Only available for Tensor DS/DL.
E535 Torque transducer error Yes Cables to transducer cut off or
shorted.
E536 No transducer (sensor) Yes Cables to transducer cut off or
shorted.
E537 Calibration not OK,
offset outside limits
Yes Calibration limits out of bounds.
E538 Calibration not OK,
CalVal outside limits
Yes Calibration value outside limits.
E539 Calibration not OK,
Offset changed > 5%
of max value since last
calibration
- Calibration not OK, Offset changed >
5% of max value since last calibration.
