SmartROC T45-10 3 Controls and Instruments
12
3.1 OperatingControls
OperatingPanel
A Modeselector
1. Positioningmode
2. Drillmode
3. Trammode
4. Winchmode/Remotecontrolmode
B Flushair
C Watermist
D DustCollector(DCT)
E Tramminglevers
F Trackoscillationlevers
G DisplayEscapebutton
H DisplayTogglebutton
J DisplayNavigationknob
K SignalHorn
L Preheating(hydraulicoil)
M Jackin
N Jackout
