Atlas Copco SmartROC T45--10

SmartROC T45-10 7 Technical Data
85
7.3.7DrillRigSetup:theFeedTopinExtremePositionForwardand
totheLeft,andwiththeBoomSwungMaximumtotheLeft
DrillRigSetup:theFeedTopinExtremePositionForwardandtotheLeft,andwiththeBoomSwung
MaximumtotheLeft
Direction MaximumAngleofInclina
tion(°)
A Forward 20
B Reverse 20
C Left 9
D Right 20
