Atlas Copco SmartROC T45--10

SmartROC T45-10 7 Technical Data
84
7.3.6DrillRigSetup:theFeedTopinExtremePositionForward,the
FeedLaterallyVerticalandCenteredBetweentheTrackFrames
DrillRigSetup:theFeedTopinExtremePositionForward,theFeederLaterallyVerticalandCentered
BetweentheTrackFrames
Direction MaximumAngleofInclina
tion(°)
A Forward 15
B Reverse 20
C Left 20
D Right 20
