SmartROC T45-10 3 Controls and Instruments

3.5 RightLeverinTramMode/PositioningMode

RightLeverinTramMode/PositioningMode

Boomlowering

Boomlift

Boomswingleft

Boomswingright

Boomextensionout

Boomextensionin

ConfirmsuggestedholeHNSsystem
