Atlas Copco SmartROC T45--10

SmartROC T45-10 7 Technical Data
86
7.3.8DrillRigSetup:theFeedTopinExtremePositionForwardand
totheRight,andwiththeBoomSwungMaximumtotheRight
DrillRigSetup:theFeedTopinExtremePositionForwardandtotheRight,andwiththeBoomSwung
MaximumtotheRight
Direction MaximumAngleofInclina
tion(°)
A Forward 17
B Reverse 20
C Left 20
D Right 9
