Engine
1)
With filter change.
Designation
Number of compression stages 2
Designation
XRYS 577 -
XRYS 1260
XRXS 607 -
XRXS 1275
XRVS 647 -
XRVS 1350
Make Caterpillar Caterpillar Caterpillar
Type C18 C18 C18
Coolant Liquid Liquid Liquid
Number of cylinders 6 6 6
Bore mm 145 145 145
in 5.71 5.71 5.71
Stroke mm 183 183 183
in 7.2 7.2 7.2
Swept volume l 18.1 18.1 18.1
cu.in 1104.5 1104.5 1104.5
Maximum power
output (according to
SAE J1995)
kW 447 447 447
hp 599 599 599
Engine Rating IND-B IND-B IND-B
Designation All units
Capacity of oil sump:
- Initial fill l 64
US gal 16.9
- Refill (max.)
1)
l62
US gal 16.4
Capacity of cooling system l 78.6
US gal 20.8
