- 48 -
TOWING INSTRUCTIONS
1. Attach the compressor to the towing vehicle.
2. Move hand brake lever (1) in the direction of the
arrow till stop and connect the breakaway chain
(2) to the towing vehicle.
Never move the compressor with air hoses connected
to the air outlet valves.
WAGON
Towbar levelling
The towbar of the wagon is equipped with an
adjustable spring loaded levelling device.
To adjust:
1. Slide back the rubber bellows (1).
2. Turn the nut (2) clockwise to increase the spring
load for lifting the towbar; turn the nut (2) counter
clockwise to decrease the spring load for lowering
the towbar.
3. Slide the bellows (1) over the nut.
TANDEM EU
Adjust the height of the towing eye if necessary.
Loosen the bolts (1) and (3). Adjust the height of the
towing eye by turning bolt (2). After adjusting fasten
bolts (1) and (3).
Before towing the compressor, ensure
that the towing equipment of the vehicle
matches the towing eye. The height of
the towing device of the vehicle must be
815 - 845 mm (31.8 - 33 in).
Before moving the compressor, switch it
off.
