- 26 -
ELECTRIC SYSTEM
CIRCUIT DIAGRAM INDEX
9822 0963 68
Tag Desc. 1 Desc. 2 Sheet Col.
B1 Namur sensor Bypass
B2 Namur sensor Closed
B3 Combo sensor
B4 Namur sensor Bypass
B5 Namur sensor Closed
F1 Circuit breaker Main
F10 Circuit breaker 10A Roof actuator
F13 Circuit breaker Charging alternator
F2 Circuit breaker Engine control module
F3 Circuit breaker CAT regeneration system
F4 Circuit breaker Fuel priming pump
F6 Circuit breaker Refuel pump
F8 Circuit breaker 15A Internal lights
F9 Circuit breaker Preheater/Nordic
G1 Battery
G2 Battery
G3 Charging alternator
H10 Light Internal
H11 Light Internal
H4 Flasher light
H6 Horn
H7 Flasher light
H8 Light Internal
H9 Light Internal
Tag Desc. 1 Desc. 2 Sheet Col.
K0 Solenoid Starter motor
K1 Relay Fuel priming pump
K10 Relay Remote control
K11 Relay Roof actuator
K12 Relay Micro PLC
K13 Relay Etherstart
K2 Relay Compressor P.A.C.
K3 Relay Refuel pump
K4 Relay Air shut-off valve
K5 Relay Aftercooler fans
K6 Relay Internal lights
K8 Relay Heater
LS1 Level switch Coolant level warning
LS2 Level switch Coolant level shutdown
LT1 Level sensor Fuel level
M1 Starter motor
M3 Pump Refuel pump
M4 Fan Aftercooler
M5 Fan Aftercooler
M6 Pump Preheater
M7 Stepper motor Oiltronix
M8 Motor Roof actuator
M9 Stepper motor AirXpert
N1 Connector Engine control module
