Atlas Copco XRXS 607 User Manual

- 27 -
9822 0963 68
Tag Desc. 1 Desc. 2 Sheet Col.
PS1 Pressure switch ΔP airfilter
PT1 Pressure sensor Vessel pressure
PT2 Pressure sensor Regulating pressure
PT3 Pressure sensor Interstage pressure
PT4 Pressure sensor Oil Stop valve pressure
PT5 Pressure sensor Aftercooler air discharge
pressure
R1 End resistor J1939 CAN Bus
R2 End resistor J1939 CAN Bus
S10 Switch Emergency stop
S11 Switch Battery cut-off
S12 Switch Remote emergency stop
S13 Switch Battery cut-off
S10 Switch Emergency stop
S2 Switch External fuel
S3 Switch Fuel priming pump
S4 Switch Battery cut-off
S5 Switch Emergency stop
S6 Switch Dual pressure
S8 Switch Limit switch
S9 Switch Internal lights
TT1 Temperature sensor LP element temperature
TT2 Temperature sensor HP element temperature
TT3 Temperature sensor Ambient temperature
TT4 Temperature sensor Ambient temperature
TT5 Temperature sensor Aftercooler air discharge
temperature
TT6 Temperature sensor Air discharge temperature
Tag Desc. 1 Desc. 2 Sheet Col.
X1 Connector XC3003/4003 primary
X10A Connector Air shut-off valve
X10B Connector Preheater
X10C Connector Internal lights
X10D Connector Dual pressure/preset
X11 Remote control Receiver
X11 Remote control Receiver
X11 Remote control Receiver
X2 Connector XC3003/4003 secondary
X3 Connector XC3003/4003 remote
X4 Connector CAT diagnostic
X5 Connector CAT interconnect harness
X60 Connector COSMOS module
X61 Connector COSMOS satellite
X62 Connector COSMOS PC
X7 Connector Roof actuator controller
X8 Connector Limit switch
X9 Connector Option box
XPH1 Connector Coolant heater
XPH2 Connector Timer
Y1 Solenoid valve Load
Y2 Solenoid valve Blow down
Y4 Solenoid Etherstart
Y5 Solenoid valve Air shut-off valve
Y6 Solenoid Dual preset
Y7 Solenoid Dual pressure
