- 54 -
BASIC OPERATION OF THE MACHINE
The compressor can be controlled in 4 different
modes:
Local Operation Mode: locally at the Operating
Panel,
Remote Operation Mode: via remote switch
inputs located at the bottom of the Control panel,
Automatic Operation Mode: via pressure sensor
data from the customer's installation,
PC Operation Mode: with software running on a
PC.
In this section is described how to operate the
machine in Local Operation Mode at the Operation
Panel.
STARTING / STOPPING
Safety precautions
Make sure the fuel tank is filled up when
“INTERNAL FUEL” is selected.
BATTERY SWITCH
The compressor is equipped with a battery switch.
When the compressor is not in use this switch must
always be in the “OFF” position.
It is not allowed to use this switch as an emergency
switch or for stopping the compressor. It will cause
damage in the control unit when using this switch for
stopping.
Always first shut off the control unit and wait until the
display is dark before switching the battery switch to
position “OFF”.
Do not disconnect power supply to
control box in any way when the control
box is switched on. This will cause
memory loss.
Do not switch off the circuit breaker
when the control box is switched on. This
will cause memory loss.
Please be aware that the (optional)
preheater unit is still “live” with the
battery switch in “OFF” position.
