Atlas Copco XRXS 607 - Page 21

- 21 -
Reference Name
MPV Minimum Pressure Valve
OC Oil Cooler
OFce Oil Filter (compressor element)
OFe Oil Filter (engine)
OSE Oil Separator Element
OSV Oil Stop Valve
OT Oiltronix
PSlp Pressure Sensor (low pressure)
PSS Pressure Selection Switch
RV Regulating Valve
RVlp Regulating Valve (low pressure)
SC Safety Cartridge
SL Scavenge Line
SV Safety Valve
TBV Thermostatic Bypass Valve
TShp Temperature Sensor (high pressure)
TSlp Temperature Sensor (low pressure)
UA Unloader Assembly
WPS Working Pressure Sensor
(AFe)
(AFE)
(SC)
(AFS)
(AFce)
(DE)
(BVof)
(OFce)
(TBV)
(SL)
(WPS)
(AR)
(SV)
(OSE)
(MPV)
(RV)
(LV)
(DP)
(AOV)
(EW)
(C)
(OC)
(F)
(E)
(UA)
(BOV)
(CH)
(OFe)
(CElp)
(PSlp)
(TShp)
(OSV)
(TSlp)
(CU)
(CEhp)
(CV)
XRVS
