Plug connections (15-pin)
ABS trailer plug (7-pin)
Nr. Function Cable cross section Line colour
1 Left light indicator 1.5 mm
2
yellow
2 Right light indicator 1.5 mm
2
green
3 Rear fog light 1.5 mm
2
blue
4 Ground connection 2.5 mm
2
white
5 Left rear outline light, license plate illumination 1.5 mm
2
black
6 Right rear outline light, running light, license plate illumination 1.5 mm
2
brown
7 Brake light 1.5 mm
2
red
8 Reversing light 1.5 mm
2
gray
9 Power supply 24 V 2.5 mm
2
brown/blue
10 Sensor for brake lining wear indicator 1.5 mm
2
brown/red
11 Pressure sensor of the spring brake 1.5 mm
2
yellow/black
12 Lifting axle 1.5 mm
2
pink
13 Ground connection for data line 2.5 mm
2
white/black
14 Data line 1.5 mm
2
purple
15 Data line 1.5 mm
2
orange
Nr. Function Cable cross section Line colour
1 Plus terminal solenoid valve KL 30 4 or 6 mm
2
red
2 Plus terminal electrical system KL 15 1.5 mm
2
black
3 Minus terminal electrical system KL 31b 1.5 mm
2
yellow
4 Minus terminal solenoid valve KL 31 4 or 6 mm
2
brown
5 Warning device 1.5 mm
2
white
6 CAN HIGH 1.5 mm
2
white/green
7 CAN LOW 1.5 mm
2
white/brown
