Atlas Copco XRXS 607 User Manual

- 62 -
The engine starts crancking, the display shows
The engine cranks until 800 rpm is reached.
If 800 rpm is not reached within 30 seconds, the
starting procedure is cancelled and the engine will
rest for some time. (Resting time depends on cranking
time).
The display now shows The engine starts running at idle speed. The display
shows
The engine will run at minimum rpm, until the
engine’s coolant temperature reaches 40°C, with a
minimum time of 15 seconds and a maximum time of
300 seconds.
800RPM
324RPM
0RPM
MAIN VIEW
ENGINE CRANKING
324RPM 0.0bar41% 1286h
Active Buttons
Stop Button
(to cancel Start command)
Load Button
(to activate Automatic Load)
Measurement View Button
Settings View Button
Alarms View Button
120s
54s
0s
MAIN VIEW
ENGINE RESTING
--RPM 0.0bar41% 1286h
MAIN VIEW
ENGINE WARMING UP
1200RPM 3.3 bar41% 1286h
40˚C
25˚C
13˚C
300s
76s
0s

Atlas Copco XRXS 607 Specifications

General

Brand	Atlas Copco
Model	XRXS 607
Category	Air Compressor
Language	English
