Atlas BP8000 User Manual

Steps Of Installation 13
BP8000
F. Position Columns
Check the columns are plumb with level bar, and adjusting with the shims if the
columns are not vertical.
Fig. 13
Model BP8000: Appx. 109 ½”
Work Smart not Hard
No need to measure. Use
the base plate as a distance
gauge. Before drilling the
anchor holes, position the
columns up to each end
of the base plate. Double
check that the columns are
positioned on the chalk line.
Model BP8000: 132”
